At a glance

  • Phone call available – 2 family numbers supported
  • GSM 850 / 900 / 1800 / 1900 MHZ Quad-band
  • Accurate dual-locating by GPS and LBS
  • SOS emergency alarm
  • Large capacity internal battery for 98 hours working time
  • Geo-fence alarming function
  • Suitable for cargo, container and personal tracking
  • Two-way communication function
  • Built-in accelerating sensor for alarm function
  • Web-based online tracking platform


Dimension (L/W/H)mm 73.0×45.0×15.8
Weight 54g
Color White and Blue
Backup Battery 1200 mAh
Standby Time 98 hours
Talk Time 7 hours
GSM Frequencies Quad-band
GPRS Class 12
GPS Channel 20
GPS Sensitivity -159 dBm
Position Accuracy -144 dBm
GSM/GPS Antenna Built-in Design
Data Transmit TCP, SMS
Geo-fence View any existing Geo-fence in the map
Overspeed Alarm Alarm when over the pre-set speed
Low Power Alarm Alarm when backup battery is running out
Non-movement Detection Movement alarm based on built-in 3D motion sensor
Mileage Report Track by time / distance interval
Internal Memory 64Mb+32Mb
Communication Mode GSM

click here to view the brochure.
